Product Overview
The Shangwu Fluid W-type hydraulic injector is a mechanical device with three effective functions: vacuum pumping, condensation, and drainage. It uses a certain pressure of water flow to be sprayed out through symmetrically distributed nozzles with a certain inclination, converging at a focal point. Due to the high velocity of the jet water flow, negative pressure is formed around it, creating a vacuum inside the chamber. In addition, due to the direct contact between secondary steam and the jet water flow, heat exchange occurs, and the vast majority of the steam condenses into water. A small amount of uncondensed steam and uncondensed gas also rub against the high-speed jet water flow, mix and squeeze, and are discharged through the expansion tube, creating a higher vacuum inside the chamber. Hydraulic jets are widely used in vacuum and evaporation systems for processes such as vacuum pumping, vacuum evaporation, vacuum filtration, vacuum crystallization, drying, and deodorization. They are equipment widely needed in sugar, pharmaceutical, chemical, food, salt, MSG, milk, fermentation, as well as in light industry and national defense sectors. Adopting structures such as multiple nozzles and steam rings (guide plates), as well as multi-stage pumps for water inlet and low-level installation, it is a vacuum condensation equipment that only needs to be installed at a height of 4.5 meters.
