Product DescriptionCompany Info.<>
- Brand:
- Shangwu Fluid
- Material:
- Stainless steel
- Performance:
- Explosion-proof
- Driving mode:
- Electric
- Allowable particle value:
- 1 mm
- Suction range:
- 3 m
- Outlet pressure:
- 0.3 Mpa
- Lift:
- 30 m
- Flow:
- 0.75 m3/h
- Power:
- 0.75 kw
- Place of origin:
- China
- Model:
- DBY-15PB
product overview
The DBY series electric diaphragm pump replaces some centrifugal pumps and screw pumps for applications in industries such as petrochemicals, ceramics, and metallurgy. This pump is suitable for low-pressure applications, where the outlet pressure is ≤ 3kgf/cm2.
Model Meaning
For example: DBY-40 S
DBY - Electric Diaphragm Pump
40- Pump inlet and outlet diameter (mm)
S-refers to the material (engineering plastic)
Product Features
1. No need for irrigation, with a self-priming capacity of up to 3 meters.
2. With good performance, particles and mud with a diameter of less than 10 millimeters can pass through effortlessly.
3. Due to the separation of the conveying medium and transmission mechanical components by the diaphragm, the medium will not leak outward; And the pump itself has no shaft seal, greatly extending its service life; According to different media, diaphragms can be divided into chloroprene rubber, fluororubber, nitrile rubber, polytetrafluoroethylene, PTFE (F46), etc., which can meet the requirements of different customers.
4. The overcurrent part of the pump body medium can be divided into cast iron, stainless steel, rubber lining, aluminum alloy, engineering plastic PP, fluoroplastic PVDF, fluorine lining and other materials according to different user requirements. The motor can be divided into ordinary motor, explosion-proof motor, reduction motor and electromagnetic speed control motor.
Application scope
1. Various highly toxic, flammable, and volatile liquids.
2. Various strong acids, strong alkalis, and highly corrosive liquids.
3. Can transport media with higher temperatures up to 150 ℃.
4. As a front-end pressure feeding device for various filter presses.
5. Hot water recovery and circulation.
6. Oil tanker trucks, oil depots, and oil loading and unloading.
7. Diaphragm pump suction for kimchi jam, mashed potatoes, chocolate, etc.
8. Diaphragm pumps suck paint, gum, pigment adhesives.
9. Various porcelain glazes, cement grout, mortar slurry.
10. Various rubber pastes, latex, organic solvents, and fillers.
11. Use a diaphragm pump to clean and extract sewage and residual oil from the oil tanker barge.
12. Hops and fermented powder slurry, syrup, and molasses.
13. Electric diaphragm pump is used to suction sewage and sediment from mines, tunnels, tunnels, and sewers.- Name（chinese）
- Name（English）
- Zhejiang Shangwu Fluid Technology Co., Ltd.
- China credit code
- Identity Verification
- Registered Capital
- 10,000,000 CNY
- Operating term
- 2018-03-13 ~ ****
- Address
-
Yongjia County, Wenzhou, Zhejiang, China
- Nearby port
- Wenzhou
The company mainly sells diaphragm pumps. Pneumatic diaphragm pumps can not only pump flowing liquids, but also transport some media that are difficult to flow. They have the functions of submersible pumps, self-priming pumps, impurities pumps, shielded pumps, mud pumps and many characteristics of conveying machinery. The flow is spacious and the passing performance is good, allowing passage of particles up to 10 mm. When pumping mud and impurities, there is little wear on the pump; No need for irrigation and water diversion, outlet pressure 7bar The pneumatic diaphragm pump has no rotating parts or shaft seals. The medium pumped by the diaphragm and other is completely separated from the moving parts of the pump and the workpiece media, and the medium transported will not leak out. Therefore, when pumping toxic, volatile or corrosive media, it will not cause environmental pollution and endanger personal safety; The pneumatic pump does not require oil lubrication, and even if it is idling, it will not have any effect on the pump. This is the characteristic of this pump.- Name（chinese）
