Product DescriptionCompany Info.<>
- Brand:
- Shangwu Fluid
- Performance:
- Explosion-proof
- Driving mode:
- Electric
- Pump shaft position:
- Edge vertical type
- Material:
- PTFE
- Impeller suction mode:
- Single suction type
- Flow:
- 0.09 m3/h
- Weight:
- 30 kg
- Model:
- GM90/0.5
Technical Parameter
Measurement range: 0-400L/H
Pressure range: 0-1.0MPa
Drive mode: motor-driven
Control mode: manual, automatic control (can receive 4-20mA signal to adjust flow)
Product Features
1. Cast aluminum shell, high heat dissipation performance, light overall weight, suitable for various acid-base drugs, non-toxic and odorless.
2. Adopting a cam mechanism, there is no overall leakage and it can be placed on a medicine tank or pipeline.
3. The contact medium pump head is made of PVC, optional PTFE, and stainless steel materials.
4. High cost-effectiveness, widely applicable to the water treatment industry with low pressure requirements.
5. The flow rate can also be adjusted arbitrarily and the output can be quantified when the pump is running or stopped.
6. The diaphragm is made of multi-layer composite structure compression, with ultra tough Teflon acid resistant film, EPDM elastic rubber, a thickness of 3mm SUS304 supporting the iron core, reinforced with reinforced nylon fibers, and fully wrapped with EPDM elastic rubber, which can effectively improve the service life of the diaphragm.- Name（chinese）
- Name（English）
- Zhejiang Shangwu Fluid Technology Co., Ltd.
- China credit code
- Identity Verification
- Registered Capital
- 10,000,000 CNY
- Operating term
- 2018-03-13 ~ ****
- Address
-
Yongjia County, Wenzhou, Zhejiang, China
- Nearby port
- Wenzhou
The company mainly sells diaphragm pumps. Pneumatic diaphragm pumps can not only pump flowing liquids, but also transport some media that are difficult to flow. They have the functions of submersible pumps, self-priming pumps, impurities pumps, shielded pumps, mud pumps and many characteristics of conveying machinery. The flow is spacious and the passing performance is good, allowing passage of particles up to 10 mm. When pumping mud and impurities, there is little wear on the pump; No need for irrigation and water diversion, outlet pressure 7bar The pneumatic diaphragm pump has no rotating parts or shaft seals. The medium pumped by the diaphragm and other is completely separated from the moving parts of the pump and the workpiece media, and the medium transported will not leak out. Therefore, when pumping toxic, volatile or corrosive media, it will not cause environmental pollution and endanger personal safety; The pneumatic pump does not require oil lubrication, and even if it is idling, it will not have any effect on the pump. This is the characteristic of this pump.- Name（chinese）
